APEM On/Off/On Momentary Toggle Switch 10A SPDT

APEM momentary On/Off/On toggle switch, useful for turning on two individual circuits for a momentary period

The switch is spring loaded and rests in the off position

Suitable for panel mounting through a 12.5mm hole on race cars 4x4's and classic cars

Connections are made using 6.3mm blade terminals attached on the rear of the switch

Rated up to 250VAC at 10A

Supplied individually

All prices shown are exclusive of VAT

Specifications

• Switch Configuration: On/Off/On SPDP Momentary
• Panel Hole Size: 12.5mm
• Current Rating: 10A

• Connections:  3 x 6.3mm Male Lucar Connectors
